Description:
Showcasing the FNIRSI-1014D: an unparalleled blend of an Oscilloscope and Signal Generator. Packaged into one cutting-edge device, it features a real-time sampling rate of 1GSa/s and a remarkable 100MHz*2 analog bandwidth. No ordinary device, it comes equipped with a 7-inch TFT LCD display that elevates your experience to a new level. The device houses a high-voltage protection module that nullifies the risk of burning due to accidental incorrect probe positioning at 10x gear, tolerating up to 400V continuous voltage. An innovative highlight is its built-in DDS function signal generator which supports 14 kinds of standard function signals and a customizable chopping signal. The sophisticated output device expertly intercepts complex signals measured by the Oscilloscope, generating them as the output signal. Additionally, the device allows storage for up to 1000 customized outputs for your convenience. Key Features: Built-in DDS signal generator, supporting 12 types of function signals. Capturing output signal ability, storing up to 1000 capture signals. Intelligent decoding algorithm, infinite encoder life, and anti-burn function tolerating up to 400V. 100MHz*2 analog bandwidth with 1GSa/s sampling rate. 7-inch 800*480 resolution color TFT LCD display for high-contrast, lively imaging. Impressive voltage range capacity: 1X measures 0~40 V, 10X measures 0~400V. Capability to measure 12 parameters: VPP, VP, Vmax, Vmin, Vavg, Vrms, Frequency, Duty+, Duty-, Time+, Time-, Period. Integrated with a cursor measurement feature for easy manual measurement of frequency, period, and voltage. Complete single, normal, automatic triggering function with waveform display freeze option. One-button AUTO and waveform storage, screenshot function and integrated 1GB storage for up to 1000 screenshots and waveform data. Advanced waveform picture manager for easy browsing, viewing, page-turning, deletion and for zooming in/out and moving waveforms. USB connectivity for easy sharing of screenshots and for secondary analysis. Lissajous figures graphic display feature aids in determining amplitude, frequency, and phase contrast of two groups of signals. FFT display feature for analyzing signal spectral characteristics, utilizes memory compression technology ensuring a flicker-free refreshment of the waveform screen. Display brightness and background grid brightness adjustment options for convenience. Specifications: Material: ABS Analog bandwidth: 100MHz*2 Channels: 2 Real-time sampling rate: 1GSa/s Vertical sensitivity: 50 mV/div ~ 500 V/div Time base range: 50S/div ~ 10nS/div Maximum test voltage: 40 V (1X probe), 400 V (10X probe) Storage depth: 240Kbit Input resistance: 1M ADC precision: 8bits Coupling mode: AC/Direct Current Trigger mode: Single, Normal, Auto Trigger edge: Rising edge/Falling edge External trigger voltage: 0~40 V Extension ports: USB picture export Package size: 340 140 70mm Package weight: 2500g Package includes: 1 x FNIRSI-1014D Oscilloscope Host 2 x Matching 100MHz Probe (1X and 10X) 1 x Clip 1 x 5V2A Power Adapter 1 x USB Data Line 1 x English User Manual
