Description:
Dive into the realm of frequencies with this portable DDS Function Signal Generator. Its compact size, powered by a DC 9V, makes it your perfect on-the-go companion for frequency generation – anytime, anywhere. Boasting a DDS frequency range of 1Hz-65534Hz, it’s no slouch when it comes to speed. The high-speed (HS) output can skyrocket up to a staggering 8MHz, easily catering to all your frequency needs. What’s more, two independent potentiometers enable precise tuning of the DDS signal amplitude. So, you can dial in the desired offset amount for each of your applications. But that’s not all. This incredible machine can generate a variety of DDS signals for all occasions. From sine waves and square waves to sawtooth, reverse sawtooth, and triangle waves, it’s got you covered. Feeling a bit adventurous? You can even generate the ECG wave or a simple noise wave. Operating this device is a breeze too, thanks to its intuitive LCD display, and easy-to-use touch buttons. And what’s more, the gadget remembers your last used configuration and restores it, ensuring you don’t have to reset your parameters every time. So, what are the operations? The “UP” and “DOWN” buttons are used to select the output waveform, while the “LEFT” and “RIGHT” buttons are employed to adjust the output frequency. And to stop or start the output, just hit the “STOP/START” button. As for the “UP” key waveform order, you have the option of ECG (Electrocardiogram wave), Rev Sawtooth (Reverse Sawtooth), SawTooth, Triangle, and Square. Our DDS Function Signal Generator is crafted from durable ABS material and measures 1358032mm. The On-screen readings are clearly displayed on a 1602 LCD screen. The frequency section serves values of 1, 10, 100, 1000, and 10000 Hz. The offset range is from 0.5pp-5Vpp, and the amplitude is between 0.5Vpp to 14 Vpp. In short, it’s a compact powerhouse of features! Included in the package is 1 x DDS Function Signal Generator and 1 x Power Cable. So, get ready to harness the power of frequencies with this handy, capable tool! For a closer look, please see the images below:
